LMK107BBJ226MA-T, CAP, 22uF, 10V, ±20%, X5R(EIA), 0603 Multilayer Ceramic Capacitors (High dielectric type)

Name: LMK107BBJ226MAT CAP 22uF 10V 20 X5REIA 0603 Multilayer Ceramic Capacitors High dielectric type
Brand: TAIYO YUDEN
Price: 1 USD

Brand Name : TAIYO YUDEN

Model Number : LMK107BBJ226MA-T

Certification : Original Part

Place of Origin : Shenzhen, China

MOQ : 4000PCS

Price : Contact us for Latest Pricing

Payment Terms : T/T, Western Union, Paypal, Wechat Pay

Supply Ability : 10,000,000PCS per Week

Delivery Time : 2~5 Working Days (Subjected to availability of Stock)

Packaging Details : 4000PCS, Taping paper

Capacitance : 22uF

Tolerance : ±20%

Rated Voltage : 10V

Operating Temperature : -55°C ~ 85°C

Packing : 4000PCS, Taping paper

Soldering : Reflow

Product Type : Multilayer Ceramic Capacitors (High dielectric type)

Size : X5R, 0603/1608 (EIA/JIS)

Description : CAP, 22uF, 10V, ±20%, X5R(EIA), 0603

Contact Now

LMK107BBJ226MA-T, CAP, 22uF, 10V, ±20%, X5R(EIA), 0603 Multilayer Ceramic Capacitors (High dielectric type) SMD Ceramic Capacitor MLCC chip capacitors

Products Characteristics Table :

Capacitance : 22uF ±20%
Case Size (EIA/JIS) : 0603/1608
Rated Voltage : 10V
tanδ (max) : 10%
Temperature Characteristic (EIA) : X5R
Operating Temp. Range (EIA) : -55 to +85℃
High Temperature Loading : 150% (% Rated Voltage)
Insulation Resistance (min) : 100 MΩ·μF
RoHS Compliance (10 subst.) : Yes
REACH Compliance (197 subst.) : Yes
Halogen Free : Yes
Soldering : Reflow

Electrical Characteristics Data :

LMK107BBJ226MA-T, CAP, 22uF, 10V, ±20%, X5R(EIA), 0603 Multilayer Ceramic Capacitors (High dielectric type)

External Dimensions :

Dimension L : 1.6 +0.20/-0.00 mm
Dimension W : 0.8 +0.20/-0.00 mm
Dimension T : 0.8 +0.20/-0.00 mm
Dimension e : 0.35 ±0.25 mm

for product datasheet, CONTACT US directly.

Product Tags:

low voltage capacitor

single layer ceramic capacitor

Quality LMK107BBJ226MA-T, CAP, 22uF, 10V, ±20%, X5R(EIA), 0603 Multilayer Ceramic Capacitors (High dielectric type) wholesale

LMK107BBJ226MA-T, CAP, 22uF, 10V, ±20%, X5R(EIA), 0603 Multilayer Ceramic Capacitors (High dielectric type) Images
